Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water

Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water
Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water

Large Image :  Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water

Product Details:
Place of Origin: China
Brand Name: Daruifuno
Certification: CE
Model Number: ASP500-NYD05
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Carton
Delivery Time: 5-20 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000 Sets per Month

Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water

Description
Product Name: PH Sensor Materials: ABS+Glass+ceramics +SUS316
PH: 0~14pH Working Temp.: 0.0~60.0℃
Working Pressure:: 0~4Bar Reference System: Double Salt Bridge
Reference Electrode: Ag/AgCl Temp. Compensation: NTC10K
Ground: SUS316 Solution Cleaning: Cleaning Interface(Optional)
High Light:

Flow Through Installation PH ORP Sensors

,

SUS316 Solution Ground PH Electrode

,

Flow Through Installation PH Electrode



Flow-Through Installation SUS316 Solution Ground PH Electrode For Pure Water



Hydrofluoric acid above a certain concentration (>1g/L) and below pH 5 will corrode the standard electrode glass membrane and prevent the formation of a gel layer. This results in unstable measurements and greatly reduces electrode life. For high hydrofluoric acid concentration measurements, antimony electrodes are recommended for measurement.



Electrodes need to be stored in an ion-rich aqueous solution. The sensitive gel layer of the pH-maintaining glass membrane contains high levels of water and ions, responding more reliably to sample pH.



Specification:

  Modle

  ASP500-NYD05
PH Range
0~14pH 0.01pH
Shaft Material
ABS
Working TEMP
0~60℃
Reference System
double salt bridge
Reference Electrode
Ag/AgCl
Electrolyte
Gel
Working Pressure
0~4Bar
Temperature Unit
NTC10K
Membrane
Ceramic hole
  Glass Head

  Blue low impedance



Dimension
Diameter: 35mm Length: 260 mm ( include the cleaning cover)
Thread Size
1 inch NTP(both ends)
Lead Wire
Standard 5m
Ground
SUS316 solution
Cleaning
A protective cover with its own cleaning interface(Optional)
Application
Pure water



Please click the catalog of pH controller here:

Daruifuno Catalog.pdf



Brief introduction:

◆ pH composite electrode, grounded with stainless steel solution, specially designed for accurate detection of pure water environment;
◆ Built-in high-precision NTC10K temperature resistance;
◆ The main body is packaged with reinforced plastic case
◆ The electrode is equipped with a protective cover with its own cleaning interface;
◆ Blue low-impedance hemispherical glass head;
◆ The reference adopts ring-shaped ceramic holes, the reference electrode is Ag/AgCl, and it is filled with KCL colorless high temperature gel;
◆ The reference system is designed with double salt bridges, and the ring-shaped ceramic holes have the characteristics of fast response, not easy to block, and easy to clean.

Flow Through Installation SUS316 Solution Ground PH Electrode For Pure Water 0

Aplication:

Water treatment monitoring

Drinking water,surface water,water quality analyze,ground water,ect.



Industrial process monitoring and dosing control

Chemical,petroleum,paper,food and medicine,PCB manufacturing,etc.



FAQ

1. What is themeasurement principle of this pH electrode?
A:
The pH value potentiometric method uses the potential difference of glass electrodes for pH measurement.


2. How is this glass pH electrode composed?
A:
The pH electrode is usually composed of an indicator electrode and a reference electrode.


3. How to judge the pH of the solution?
A:
If the internal hydrogen ion concentration of the pH glass bulb is lower than the outside, the measured solution is recorded as acidic and the pH value is lower than 7; if the two are the same, the solution is neutral and the pH value is equal to 7; if the internal hydrogen ion concentration is higher than externally, the measured solution is alkaline and the pH value is higher than 7.



4. What is the wire length of the pH electrode?
A: The lead wire of this electrode is 5m by default, other lengths need to be customized, contact our customer service, the price will vary with the change of length.



5. How often must the pH sensor be calibrated?
A: Depends on the type of sample:
Dirty samples and non-aqueous samples require more frequent calibration.
Depends on the required accuracy:
For very accurate measurements, at least daily calibration is required.
Depends on the quality of the electrode:
Old electrodes require more frequent calibration.
